Camera
Model
EL-852T38I-S6
Image Sensor
1/2.8” 2MP Sony STARVIS CMOS
Effective Pixels
1920 * 1080
Flash / DDR
1Gb / 2Gb
IR LED No.
4 (Smart IR)
IR Distance
50m
S/N Ratio
> 52dB
Lens
Lens Type
Motorized
Mount Type
Board-in
Focal Length
3.35mm ~ 10.05mm
Aperture
F1.7 ~ 3.0
FOV
38° ~ 107°
Optical Zoom
3X
Video
Compression
H.265 / H.264
Resolution
1080P (1920 x 1080) / 1.3MP (1280 x 960) / 720P (1280 x 720)
Bitrate Control
CBR / VBR
Bitrate
1024Kbps ~ 4Mbps
Multi-Streaming
Main Stream
1080P@25fps / 960P@25fps / 720P@25fps
Sub Stream
D1 (704 * 576 )@25fps / VGA@25fps / Q720P@25fps
Third Stream
1080P@25fps
Motion Detection
Support
Digital Zoom
Support
Day / Night
Support
White Balance
Support
Corridor Mode
Support
Defog
N/A
Noise Reduction
2D/3D DNR
HLC
N/A
Mirror / Flip
Support
BLC
Support
ROI
4 areas
Anti-flicker
Support
IVA
Intelligent Video
Face Recognition
Facial Detection
Face Templates
2000
Face Detected Per Frame
30
Detected Face Size
80 x 80 ~ 300 x 300 Pixels
Face Quality Filtering
Support
Detection Area
User-defined
Capture Response
≤200ms
Network
Protocol
TCP/IP, UDP, HTTP, HTTPS, DHCP, RTSP, DDNS, NTP, PPPoE, UPnP, SMTP, FTP
Interoperability
ONVIF Profile S, SDK, AP
Max. Online Users
3
Web Browser
IE / Firefox / Chrome / Safari
Management Software (VMS)
AntarVis 2.0
ZKBioSecurity IVS
ZKBio Access IVS
Operation System
Windows
Mobile APP
AntarView Pro
P2P Cloud Service
Support
Interface
Ethernet
1 RJ-45 port (10/100Mbps)
Audio I/O
1/0
Alarm I/O
N/A
RS485
N/A
Reset Button
N/A
Micro-SD Slot
N/A
ANR
N/A
USB
N/A
General
Power Supply
PoE (IEEE802.3af ), DC 12V±10%
Power Consumption
< 3W
Ingress Protection
IP67
Dimensions (L*W*H)
Φ102 * 93.2 (mm)
Working Temperature
Φ102 * 93.2 (mm)
Working Humidity
0% to 90%
Net Weight
0.50kg
Gross Weight
0.70kg
Ordering Information
Camera
2MP Camera
Model
EL-852T38I-S6
Description
2MP Motorized Lens
Fac Recognition Eyeball IP Camera
